Moving beam shot blasting machine



Fields of application

Application areas of AGTOS travelling beam shot blasting machine (HB type)

Delicate parts are transported through the shot blasting machine using the walking beam principle. Each part is individually lifted, advanced and gently deposited.



Industrial process

The industrial process of the traveling beam shot blasting machine

The parts are placed manually or are delivered to the shot blasting machine by a conveyor belt and are automatically separated.


The shot blasting process starts as soon as the workpiece reaches the inlet threshold. The workpiece moves smoothly through the shot blasting machine automatically and is fed manually or automatically to the next processing step after the shot blasting process.


The abrasive continues to circulate and is cleaned to allow for continued use. An abrasive dosing device is used to transport the clean abrasive from the storage hopper to the high-performance turbine.


A fan creates the partial vacuum required to maintain dust-free operation of the shot blasting machine. The extracted air is cleaned by an on-site filter system.
